RAILWAY TRACK TESTING ULTRASONIC PROBE FORWARD/BACKWARD

Name: RAILWAY TRACK TESTING ULTRASONIC PROBE FORWARD/BACKWARD
Brand: KIRTI NDT AND ENGINEERING SERVICES
Price: 15000.0 INR
Availability: InStock

Price 15000.0 INR/ Unit

Get a Price/Quote

MOQ : 2 Units

RAILWAY TRACK TESTING ULTRASONIC PROBE FORWARD/BACKWARD Specification

Automation Grade
Semi-automatic

Response Time
Instantaneous ( 1 second)

Resolution
0.1 mm

Test Range
0-600 mm (depth in steel)

Interface Type
USB, Data Output Port

Operating Voltage
12 V DC / 220 V AC

Port Size
Standard probe connector (Lemo/BNC)

Humidity
Up to 95% RH, non-condensing

Measuring Range
Up to 600 mm depth

Application
Railway track flaw detection and maintenance

Equipment Type
Ultrasonic Inspection System

Hardness
Probe tip: 60 HRC

Frequency
2-5 MHz (selectable)

Accuracy
1% of measured depth

Mounting Type
Handheld with optional rail trolley

Specimen Size
Standard railway track sections

Max Height
130 mm (with handle)

Features
Forward and backward operation, water-proof design, quick probe replacement, data storage, audible flaw indication

Power Supply
Rechargeable Li-Ion battery pack or 220V AC adapter

Number of Specimens
Single or multiple rails

Temperature
-10C to +55C

Display Type
Digital LCD with backlight

Usage
Non-destructive testing of rail tracks

Capacity
Detects micro- and macro-cracks up to 2 mm

Machine Weight
4.5 kg

Test Speed
Adjustable, up to 20 m/min

Test Width
Standard railway track gauge

Test Stroke
Full rail length

Control Mode
Manual and automatic

Probe Type
Dual element ultrasonic (forward/backward)

Battery Backup
Up to 8 hours continuous use

Couplant Type
Water or dedicated ultrasonic gel

Language Support
Multi-language interface

Alarm
Visual & audible defect alarm

IP Rating
IP65 (dust & water protected)

Data Storage Capacity
500 test results

Calibration
Automatic and manual modes

Compliance Standards
EN1330, ASTM E114, Indian Railways Standard

Pulse Type
Square wave/Spike

RAILWAY TRACK TESTING ULTRASONIC PROBE FORWARD/BACKWARD Trade Information

Minimum Order Quantity
2 Units

Supply Ability
100 Units Per Month

Delivery Time
7 Week

About RAILWAY TRACK TESTING ULTRASONIC PROBE FORWARD/BACKWARD

Experience premier railway maintenance with the First-string RAILWAY TRACK TESTING ULTRASONIC PROBE FORWARD/BACKWARD. This heroic Ultrasonic Inspection System offers dual element technology and adjustable testing speed for rapid, precise flaw detection, even in challenging conditions. Enjoy up to 8 hours of battery backup, intuitive calibration options, and robust IP65 dust and water protection. Data storage for 500 results simplifies maintenance tracking. Add to Cart now-seize a Special Rate for a limited time! Perfect for exporters, suppliers, and rail operators across India.

Unmatched Features, Versatile Application, Superior Performance

The RAILWAY TRACK TESTING ULTRASONIC PROBE FORWARD/BACKWARD boasts extra features like instant visual and audible defect alarms, multi-language digital LCD interface, and automatic/manual calibration. This equipment shines in non-destructive testing applications, easily detecting both micro- and macro-cracks up to 600 mm depth on standard railway track surfaces. Whether handheld or with an optional rail trolley, it adapts to various conditions, serving maintenance, inspection, and flaw detection needs across diverse railway tracks.

Supply Ability, Packaging, Main Markets, and Payment Options

Our premier ultrasonic track tester is available with reliable supply ability to meet nationwide demand. Each unit is carefully packaged to ensure safe delivery for domestic or export market requirements. We serve the vast Indian railway sector as the main domestic market, with options to charge through flexible payment terms. We also support global supply as an exporter, ensuring every device is ready to perform upon arrival, complete with accessories and user-friendly documentation.

FAQ's of RAILWAY TRACK TESTING ULTRASONIC PROBE FORWARD/BACKWARD:

Q: How does the dual element ultrasonic probe function in railway track testing?

A: The dual element ultrasonic probe sends and receives ultrasonic pulses, providing forward and backward flaw detection along the full rail length. This enables accurate identification of cracks and defects in real time.

Q: What surfaces and specimen sizes can be tested with this ultrasonic probe?

A: The system is designed for standard railway track sections and gauges, capable of scanning single or multiple rails and detecting flaws up to 600 mm deep.

Q: What is the process for storing and exporting test results?

A: Results from up to 500 tests can be stored internally. Data can be exported conveniently using the device's USB or data output port for further analysis or reporting.

Q: When should calibration be performed on this equipment?

A: Calibration can be done automatically or manually before every testing session. Regular calibration ensures high measurement accuracy and maintains compliance with industry standards.

Q: What are the benefits of the visual and audible defect alarms?

A: These alarms provide instant notifications of detected flaws, allowing operators to react swiftly and improve safety during maintenance and inspection operations.
